Edge Intelligence.
Direkt auf dem Chip.

#include "driver/i2s.h"
#include "esp_dsp.h"
#include "wakeword_model.h"  // TFLite INT8 Modell

// I²S-Konfiguration für INMP441 MEMS-Mikrofon
const i2s_config_t i2s_config = {
  .mode             = (i2s_mode_t)(I2S_MODE_MASTER | I2S_MODE_RX),
  .sample_rate      = 16000,
  .bits_per_sample  = I2S_BITS_PER_SAMPLE_32BIT,
  .channel_format   = I2S_CHANNEL_FMT_ONLY_LEFT,
  .communication_format = I2S_COMM_FORMAT_STAND_I2S,
  .intr_alloc_flags = ESP_INTR_FLAG_LEVEL1,
  .dma_buf_count    = 4,
  .dma_buf_len      = 512,
};

// MFCC-Extraktion: 40 Koeffizienten, 25ms Fenster, 10ms Hop
const int N_MFCC     = 40;
const int FRAME_LEN  = 400;  // 25ms @ 16kHz
const int HOP_LEN    = 160;  // 10ms @ 16kHz
const int N_FRAMES   = 49;   // 1s Audio
float mfcc_buffer[N_FRAMES * N_MFCC];

bool detectWakeword() {
  // 1. PCM-Daten per DMA lesen
  int32_t raw[FRAME_LEN];
  size_t bytes_read;
  i2s_read(I2S_NUM_0, raw, sizeof(raw), &bytes_read, 100);

  // 2. Normalisieren & MFCC berechnen (esp-dsp)
  compute_mfcc_frame(raw, mfcc_buffer, N_MFCC);

  // 3. TFLite Inferenz
  TfLiteTensor* in = interpreter->input(0);
  memcpy(in->data.f, mfcc_buffer, sizeof(mfcc_buffer));
  interpreter->Invoke();

  TfLiteTensor* out = interpreter->output(0);
  float confidence = out->data.f[1];  // Klasse "Hey ESP"

  return confidence > 0.85f;
}

#include "esp_camera.h"
#include "img_converters.h"
#include "mobilenet_model.h"

// ESP32-CAM AI Thinker Pinout
const camera_config_t cam_config = {
  .pin_pwdn  = 32, .pin_reset = -1,
  .pin_xclk  = 0,
  .pin_sscb_sda = 26, .pin_sscb_scl = 27,
  .xclk_freq_hz = 20000000,
  .pixel_format = PIXFORMAT_GRAYSCALE,  // Graustufen spart RAM
  .frame_size   = FRAMESIZE_96X96,      // MobileNet Eingabegröße
  .fb_count     = 1,
};

void classifyFrame() {
  camera_fb_t* fb = esp_camera_fb_get();
  if (!fb) return;

  // Pixelwerte normalisieren: [0,255] → [-1.0, 1.0]
  TfLiteTensor* input = interpreter->input(0);
  for (int i = 0; i < 96 * 96; i++) {
    input->data.f[i] = (fb->buf[i] / 127.5f) - 1.0f;
  }

  // Inferenz (~55ms bei 240MHz)
  interpreter->Invoke();

  // Top-1 Klasse ermitteln
  TfLiteTensor* out = interpreter->output(0);
  int   best_cls  = 0;
  float best_conf = out->data.f[0];

  for (int c = 1; c < NUM_CLASSES; c++) {
    if (out->data.f[c] > best_conf) {
      best_conf = out->data.f[c];
      best_cls  = c;
    }
  }

  Serial.printf("%s (%.1f%%)\n",
    labels[best_cls], best_conf * 100.0f);

  esp_camera_fb_return(fb);
}

#include "MPU6050.h"
#include "autoencoder_model.h"  // INT8 Autoencoder

const int WINDOW   = 128;  // 128 Samples @ 200 Hz = 640ms
const int FEATURES = 6;   // ax,ay,az, gx,gy,gz
float window_buf[WINDOW * FEATURES];

float reconstructionError() {
  // Input-Tensor befüllen
  TfLiteTensor* in = interpreter->input(0);
  memcpy(in->data.f, window_buf, sizeof(window_buf));

  interpreter->Invoke();

  // MSE zwischen Eingabe und Rekonstruktion
  TfLiteTensor* out = interpreter->output(0);
  float mse = 0.0f;
  int   n   = WINDOW * FEATURES;
  for (int i = 0; i < n; i++) {
    float diff = window_buf[i] - out->data.f[i];
    mse += diff * diff;
  }
  return mse / n;
}

void loop() {
  collectIMUWindow(window_buf, WINDOW);
  float err = reconstructionError();

  const float THRESHOLD = 0.032f;  // Aus Validierungsdaten ermittelt
  if (err > THRESHOLD) {
    Serial.printf("[ALARM] Anomalie! MSE=%.4f\n", err);
    sendMQTTAlert(err);            // IoT-Backend benachrichtigen
    triggerWarningLED();
  } else {
    Serial.printf("[OK] MSE=%.4f\n", err);
  }
}

; PlatformIO-Konfiguration für ESP32 TinyML Projekt
; Stand: Juli 2026 — ESP-IDF 5.4 / arduino-esp32 3.x
[env:esp32dev]
platform  = espressif32
board     = esp32dev
framework = arduino

; Empfohlene Partition: 4 MB Flash für Modell + OTA
board_build.partitions = huge_app.csv
monitor_speed          = 115200
upload_speed           = 921600

; TensorFlow Lite Micro + DSP Bibliotheken
lib_deps =
  tensorflow/TensorFlowLite_ESP32
  espressif/esp-dsp
  lorol/LittleFS_esp32   ; Modell aus SPIFFS laden

; Optimierungsstufe für Inferenzgeschwindigkeit
build_flags =
  -O3
  -DCORE_DEBUG_LEVEL=0
  -DESP_NN                  ; Espressif Neural Network Ops
  -DTFLITE_SCHEMA_VERSION=3

; Konvertierungsbefehl (auf Host-Maschine ausführen):
; tflite_convert --output_format=TFLITE \
;   --post_training_quantize \
;   --input_file=model.h5 \
;   --output_file=model.tflite
;
; xxd -i model.tflite > model_data.h
